How to use an ultra high speed intelligent metal band saw to cut # 45 steel with a cutting speed of
27 Jun February 2025 | LionNord
The machine adopts servo motor screw lifting for more stable sawing
Adopting reducer transmission
Specially designed for efficient sawing, tackling challenges such as difficult cutting of superhard materials and slow sawing efficiency
The cutting efficiency of cutting the same material is more than twice that of ordinary machines, and the efficiency of cutting hard materials is more obvious
Exclusive design patent product
BSVP360CNC
Sawing speed increased by 100%
saw blade life increased by 50%
Automatic Intelligent speed regulation
Stronger machine design structure
Hard material cutting nemesis
Model No. | BSVP360CNC | |
Technical Data | Cutting capacity(mm) | 360mm for Round Shape 360X360 for square Shape |
Blade speed(m/min) | 10-80m/min inverter speed | |
Blade size(mm) | 34×1.1 | |
Main Motor(kw) | 7.5 (4P) | |
Hydraulic Motor(kw) | 0.75 | |
Coolant Pump(kw) | 0.09 | |
Work piece Clamping | Hydraulic Vise | |
Blade Tension | Hydraulic | |
Main Drive | Worm wheel drive | |
Chip conveyor | Automatic | |
Material feed | Auto | |
Multiple feed | 400mmx999 times | |
Machine size | 2350×3500×1650 | |
Machine weight | 3500kg | |
