Heavy-Duty CNC Automatic High Precision Aluminum Plate Cutting Machine Up to 200mm Thickness
03 Mar February 2026 | LionNord
CNC automatic aluminum plate sawing machine aluminum beam saw
Features of the CNC aluminum saw:
High speed precision cutting
High sawing efficiency
Low operating costs;
Adopting servo motor feeding;
Touch screen control panel, suitable for all operations,
Manual and automatic control modes
Model No. | New | |
Max length*width | 4000*4000 | |
Max height | 200mm | |
Blade | speed | 1800-3000 rpm |
size | 700mm | |
tension | Hydraulic | |
Motor power | blade | 30kw |
Move motor | 1.5kw | |
Saw head move speed | Max 8m/min | |
Saw head return speed | Max 17m/min | |
Coolant way | Oil mist | |
Top clamp | pneumatic | |
coolant | Oil/water | |
material feed | Servo motor 2.9kw | |
Material feed speed | Max 12m/min | |
Return speed | Max 25m /min | |
Air pressure | ≥5.0 kg/cm2 | |
Blade cutting | Servo motor stepless speed | |
Machine weight | 9500kg (exclude table) | |
Machine size(L×W×H) | 7320×6920×2100 | |
This heavy-duty CNC automatic aluminum plate cutting machine is designed for high-efficiency and high-precision cutting of aluminum plates up to 200mm in thickness.
Adopting advanced CNC control system, stable transmission structure and high-rigidity body, it ensures stable operation, fast cutting speed and excellent cutting quality.
With fully automatic feeding, positioning and cutting functions, the machine greatly reduces manual operation and improves production efficiency.
It features high cutting precision, smooth cut surface without burrs, and reliable performance for long-term industrial use.
Suitable for aluminum plates, aluminum sheets, aluminum blocks and other non-ferrous metal materials, it is widely used in aluminum processing,
machinery manufacturing, mold fabrication, automotive, aerospace and other industrial fields.
